F-B-M1101EPL

Dimension
Ø11.4 x 9 mm

Rated Voltage
1.5 Vo-p

Operating Voltage
1-2 Vo-p

Sound Pressure Level
≥85 dB(A) at 10 cm

Resonance Frequency (F0)
2048 Hz

Operating Temperature
-20 to +70 °C

Resistance
16 ±4 Ω

F-B-M1106EPL

Dimension
Ø11.4 x 9 mm

Rated Voltage
6 Vo-p

Operating Voltage
5-7 Vo-p

Sound Pressure Level
≥85 dB(A) at 10 cm

Resonance Frequency (F0)
2048 Hz

Operating Temperature
-20 to +70 °C

Resistance
42 ±4 Ω

F-B-M1112EPL

Dimension
Ø11.4 x 9 mm

Rated Voltage
12 Vo-p

Operating Voltage
6 - 15 Vo-p

Sound Pressure Level
≥85 dB(A) at 10 cm

Resonance Frequency (F0)
2048 Hz

Operating Temperature
-20 to +70 °C

Resistance
140 ±14 Ω

F-B-M1201EPB

Dimension
Ø12 x 9 mm

Rated Voltage
1.5 Vo-p

Operating Voltage
1-2 Vo-p

Sound Pressure Level
≥85 dB(A) at 10 cm

Resonance Frequency (F0)
2048 Hz

Operating Temperature
-20 to +70 °C

Resistance
16 ±4 Ω

F-B-M1206EPB

Dimension
Ø12 x 9 mm

Rated Voltage
6 Vo-p

Operating Voltage
5-7 Vo-p

Sound Pressure Level
≥85 dB(A) at 10 cm

Resonance Frequency (F0)
2048 Hz

Operating Temperature
-20 to +70 °C

Resistance
42 ±4 Ω

F-B-M1212EPB

Dimension
Ø12 x 9 mm

Rated Voltage
12 Vo-p

Operating Voltage
6 - 15 Vo-p

Sound Pressure Level
≥85 dB(A) at 10 cm

Resonance Frequency (F0)
2048 Hz

Operating Temperature
-20 to +70 °C

Resistance
140 ±14 Ω

F/DG 06 P S/L

Dimension
Ø16 x 14 mm

Rated Voltage
5 Vo-p

Operating Voltage
3 - 7 Vo-p

Sound Pressure Level
≥90 dB(A) at 10 cm

Resonance Frequency (F0)
2048 Hz

Operating Temperature
-40 to +85 °C

Resistance
45 ±6 Ω

F/DG 09-03-2.7

Dimension
Ø9.2 x 5.5 mm

Rated Voltage
3 Vo-p

Operating Voltage
2 - 5 Vo-p

Sound Pressure Level
≥87 dB(A) at 10 cm

Resonance Frequency (F0)
2731 Hz

Operating Temperature
-25 to +70 °C

Resistance
25 ±4 Ω

F/DG 105P

Dimension
Ø12 x 5.5 mm

Rated Voltage
1.5 Vo-p

Operating Voltage
1 - 2 Vo-p

Sound Pressure Level
≥70 dB(A) at 10 cm

Resonance Frequency (F0)
2048 Hz

Operating Temperature
-20 to +70 °C

Resistance
50 ±7.5 Ω

F/DG 105P-01

Dimension
Ø12 x 5.5 mm

Rated Voltage
1.5 Vo-p

Operating Voltage
1 - 2 Vo-p

Sound Pressure Level
≥70 dB(A) at 10 cm

Resonance Frequency (F0)
2048 Hz

Operating Temperature
-20 to +70 °C

Resistance
50 ±7.5 Ω

F/DG 12 P S/L

Dimension
Ø16 x 14 mm

Rated Voltage
12 Vo-p

Operating Voltage
7 - 15 Vo-p

Sound Pressure Level
≥90 dB(A) at 10 cm

Resonance Frequency (F0)
2048 Hz

Operating Temperature
-20 to +70 °C

Resistance
115 ±16 Ω

F/DG 12P S/L-09

Dimension
Ø16 x 14.5 mm

Rated Voltage
12 Vo-p

Operating Voltage
6 - 18 Vo-p

Sound Pressure Level
98 ±3 dB(A) at 10 cm

Resonance Frequency (F0)
2048 Hz

Operating Temperature
-40 to +100 °C

Resistance
115 ±15 Ω

F/DGX 05P with label

Dimension
Ø12 x 9 mm

Rated Voltage
6 Vo-p

Operating Voltage
4 - 7 Vo-p

Sound Pressure Level
≥90 dB(A) at 10 cm

Resonance Frequency (F0)
2400 Hz

Operating Temperature
-40 to +85 °C

Resistance
45 ±5 Ω

F/DGX 12P WITH LABEL

Dimension
Ø12 x 9 mm

Rated Voltage
12 Vo-p

Operating Voltage
7 - 16 Vo-p

Sound Pressure Level
≥90 dB(A) at 10 cm

Resonance Frequency (F0)
2400 Hz

Operating Temperature
-20 to +70 °C

Resistance
140 ±12 Ω

F/DGX05PA WITH LABEL

Dimension
Ø12 x 9 mm

Rated Voltage
6 Vo-p

Operating Voltage
4 - 7 Vo-p

Sound Pressure Level
≥90 dB(A) at 10 cm

Resonance Frequency (F0)
2400 Hz

Operating Temperature
-40 to +85 °C

Resistance
45 ±5 Ω

F/PCW-04A

Dimension
Ø12 x 13.5 x 7.5 mm

Rated Voltage
1.5 Vo-p

Operating Voltage
1 - 2 Vo-p

Sound Pressure Level
≥83 dB(A) at 10 cm

Resonance Frequency (F0)
2048 Hz

Operating Temperature
-20 to +60 °C

Resistance
6.5 ±1.5 Ω

Magnetic-THT-Buzzer without oscillator

F-B-M1101EPL

F-B-M1106EPL

F-B-M1112EPL

F-B-M1201EPB

F-B-M1206EPB

F-B-M1212EPB

F/DG 06 P S/L

F/DG 09-03-2.7

F/DG 105P

F/DG 105P-01

F/DG 12 P S/L

F/DG 12P S/L-09

F/DGX 05P with label

F/DGX 12P WITH LABEL

F/DGX05PA WITH LABEL

F/PCW-04A

Web content in constant progress. For further products please contact us.
